SKU: 101307

BSA Bottom Bracket for Shimano Road

Buy as a bundle
Sale price€319,00
Finish: Standard
Color: Black
Standard
4
4 year warranty
Durable and serviceable design
Low friction
Coated
Lifetime warranty
Durable and serviceable design
Lowest friction
Exceptional corrosion resistance
ALPHA
RS 5-Spoke
RS ALPHA
RS ALPHA Team Edition
ADR

Bundle up with any Pulley Wheel and save 15%. *This campaign can't be combined with each other or any other offers.

Notify me when available
Sale price€319,00

Product description

BSA is another way of stating English threading; it comes from British Standard Cycle. English threading on road bikes mean a 68mm wide, 34mm inside diameter shell with reverse threading on the drive side. It’s the most common threaded standard employed today. This kit works with 24mm diameter thru-axle cranks, found on Shimano, FSA, Rotor, among others.

Choose between two bearings for the cups. Standard Bearings have low drag thanks to hardened-steel races and our Ceramic balls. Coated Bearings have those same balls installed on coated, hardened-steel races for longer life and less bearing drag.

In The Box

  • 2 threaded cups with bearings.
  • 2 dust covers with built-in spacers.
  • Spacer tube.
  • All Round Grease.
  • Sticker sheet.
Compatibility matrix
Discipline
Road, Tri, and Track
SKU
101307
Net weight
92.0 g
Gross Weight
148 g
Derailleur Brand
Shimano
BB Type
BSA English Threaded 68mm
Crank Diameter
24.0
Crank Brand
Shimano
Crank Width
90.5

Lowest Friction

Optimized Power Transfer

Longest Product Lifetime

Drag

General Maintenance for CeramicSpeed Bottom Bracket and Wheel Bearings

Overview for how to clean and maintain CeramicSpeed Bearings used in Bottom Brackets and Wheel Hubs.

It is always important to follow these instructions and apply the proper maintenance to your CeramicSpeed Bottom Brackets and Bearings in order to achieve the lowest friction and the best longevity.

Installation of Shimano cranks on CeramicSpeed Bottom Brackets

CeramicSpeed Threaded Bottom Bracket installation guide

An overview for installing threaded CeramicSpeed Bottom Brackets including BSA, ITA, T47, and Colnago TF82.6/T45
